Description

PRODUCT FEATURES

Instructional Placards
Yes

Adjustments
Adjustable Back Pad and Foot Plate Platform

Resistance
265 lb / 120 kg

Seat
Vinyl, 1.5 in / 3.8 cm thick foam

Pulleys
N/A

Cable Travel
N/A

Rubber Feet
Heavy Duty Floor Protectors

Maximum User Weight
350 lb / 159 kg

Americans with Disabilities Act (ADA)
N/A

PRODUCT SPECIFICATIONS

Weight Stack
265 lb / 120 kg

Drop Down Weight
5 lb / 2.2 kg

Weight Stack Configuration
10 lb / 4.5 kg top plate
20-190 x 10 lb / 4.5 kg

Standard Frame Color
Black River, Platinum Sparkle

Optional Frame Color
N/A

Plastic Color
Ebony

Standard Upholstery Color
Black, Graphite, Blue Ridge, Burgundy, American Beauty Red

Optional Upholstery Color
Custom colors available upon request

Hand Grip Color
Black

PRODUCT DIMENSIONS & WEIGHT

Dimensions L x W x H
53.4 x 66.4 x 57.8 in / 135.6 x 168.6 x 146.8 cm

Footprint
53.4 x 66.4 in / 135.6 x 168.6 cm

Maximum workout area
53.4 x 66.4 in / 135.6 x 168.6 cm

Weight
487.4 lb / 221.1 kg

Shipping Dimensions
Box 1: 75.9 x 27.1 x 40.9 in / 192.7 x 68.8 x 103.8 cm
Box 2: 31.1 x 22.4 x 7.4 in / 78.9 x 56.8 x 18.7 cm

Shipping Weight
Box 1: 617.2 lb / 279.9 kg
Box 2: 22 lb / 9.9 kg

WARRANTY (US & CANADA)

Frame: 10 Years

Parts: 3 Years

Cables & Labor: 1 Year

Cosmetic & Wear Items: 6 Months

Upholstery & Padding: 120 Days

WARRANTY (INTERNATIONAL)

Frame: 10 Years

Parts: 3 Years

Cables & Labor: 1 Year

Cosmetic & Wear Items: 6 Months

Upholstery & Padding: 120 Days

Additional information

Weight	617.2 lbs
Dimensions	75.9 × 27.1 × 40.9 in
