Description

CONSOLE FEATURES

Display Type
22 in / 55 cm HD Capacitive Touchscreen

Resolution
1080p ISP LCD Screen

Controls
Touchscreen, On-handle Digital Controls

Workout Metrics
Speed, Incline, Distance, Vertical Meters, Calories, Calories/Hour, Heart Rate, Average Heart Rate, Pace, Elapsed Time, Time Remaining, Time of Day

Number of Programs
Thousands of Global Workouts and Studio Classes with iFIT

Preset Programs
Limitless iFIT Training Options

Google Maps
Enabled

Console Language(s)
English

Featured Languages
EN, also DE, ES, FR, IT, PT, RU, ZH

Maximum Workout Time
99:59 (99 Minutes + 59 Seconds)

Maximum Pause Time
60 Seconds

Additional Options
Quick-start Manual Mode

ENTERTAINMENT

TV Tuner
US & Canada: NTSC/ATSC, QAM, Pro Idiom, Set-Top Box Ready
International: PAL B/G, PAL I, SECAM D/K, SECAM L, DVB-T, DVB-T2, DVB-C

Closed Captioning
CC1-4, TEXT 1-4

Optional Upgrades
N/A

CONNECTIVITY

Recommended Internet Connection
Dedicated Ethernet – Cat 6

Ethernet Requirements
Cat 6 Preferred (Cat 5e or higher required)

WiFi Connection
2.4 / 5 GHz (Dedicated Ethernet Strongly Recommended)

WiFi Minimum Requirements
10 Mbps for one unit, 6 Mbps/unit for 2-3 units, 4 Mbps/unit for 4-6 units, 3 Mbps/unit for 7 or more units

Video Connections
Coax, HDMI Input

Audio Connections
3.5 mm audio out, Bluetooth

PRODUCT FEATURES

Drive System
Quiet Belt Drive System, Hutchinson J10 Space-efficient rear drive

Crank & Axle
2 PC, 20 in / 50.8 cm Stroke

Drive Belt
Quiet Belt Drive System

Pedals
Non-Skid Traction Control Pedals

Gear Ratio
8.85:1

Resistance System
400 Watt EMS Brake Resistance System

Heart Rate Monitoring
Dual EKG Pulse Sensors, ANT+ and Polar Compatible

Workout Fan
N/A

Accessory Charging
USB Charging Port

Accessory Holder(s)
Water Bottle Holder, Secure Phone Holder

Grips
Soft touch upper body grips

Positioning
Large Adjustable Leveling Feet

Transport Wheels
3.3 in / 8.38 cm plastic wheels

Color Options
N/A (Flat Black is standard color)

Unit Options
N/A

Power Options
110-120 VAC, 2 Amp
220-240 VAC, 1 Amp

PRODUCT SPECIFICATIONS

Maximum User Weight
400 lb / 181 kg

Step-up Height
9.5 in / 24.1 cm

Stride Length
20 in / 50.8 cm stride length

Resistance Levels
1-24 Levels of Resistance

DIMENSIONS & WEIGHT

Product Dimensions L x W x H
87.2 x 28.5 x 71 in / 221.5 x 72.3 x 180.3 cm

Product Weight
279.4 lbs / 126.7 kg

Shipping Dimensions
91.3 x 26.2 x 33.1 in / 232 x 66.5 x 84 cm

Shipping Weight
309.4 lbs / 140.3 kg

POWER REQUIREMENTS

U.S. & Canada
Input 110~240V, Output 15V 3A

International
Input 110~240V, Output 15V 3A

HIGH-USAGE WARRANTY (US & CANADA)

Frame: 7 Years

Parts: 2 Years

Console: 2 Years

Labor: 1 Year

Cosmetic & Wear Items: 6 Months

HIGH-USAGE WARRANTY (INTERNATIONAL)

Frame: 7 Years

Parts: 2 Years

Console: 2 Years

Labor: 1 Year

Cosmetic & Wear Items: 6 Months

LOW-USAGE WARRANTY (US & CANADA)

Frame: 7 Years

Parts: 3 Years

Console: 3 Years

Labor: 3 Years

Cosmetic & Wear Items: 6 Months

LOW-USAGE WARRANTY (INTERNATIONAL)

Frame: 7 Years

Parts: 3 Years

Console: 3 Years

Labor: 1 Year

Cosmetic & Wear Items: 6 Months

Additional information

Weight	309.4 lbs
Dimensions	91.3 × 26.2 × 33.1 in
