Description

CONSOLE FEATURES

Display Type
22 in / 55 cm HD Capacitive Touchscreen

Resolution
1080p ISP LCD Screen

Controls
Touchscreen, On-handle Digital Controls

Workout Metrics
Speed, Incline, Distance, Calories, Calories/Hour, Heart Rate, Average Heart Rate, Pace, Elapsed Time, Time Remaining, Time of Day

Number of Programs
Thousands of Global Workouts and Studio Classes with iFIT

Preset Programs
Limitless iFIT Training Options

Google Maps
Enabled

Console Language(s)
English

Featured Languages
EN, also DE, ES, FR, IT, PT, RU, ZH

Maximum Workout Time
99:59 (99 Minutes + 59 Seconds)

Maximum Pause Time
60 Seconds

Additional Options
Quick-Start Manual Mode

ENTERTAINMENT

TV Tuner
US & Canada: NTSC/ATSC, QAM, Pro Idiom, Set-Top Box Ready
International: PAL B/G, PAL I, SECAM D/K, SECAM L, DVB-T, DVB-T2, DVB-C

Closed Captioning
CC1-4, TEXT 1-4

CONNECTIVITY

Recommended Internet Connection
Dedicated Ethernet – Cat 6

Ethernet Requirements
Cat6 Preferred (Cat5e or higher required)

WiFi Connection
2.4 / 5 GHz (Dedicated Ethernet Strongly Recommended)

WiFi Minimum Requirements
10 Mbps for one unit, 6 Mbps/unit for 2-3 units, 4 Mbps/unit for 4-6 units, 3 Mbps/unit for 7 or more units

Video Connections
Coax, HDMI Input

Audio Connections
3.5 mm Audio Out, Bluetooth

PRODUCT FEATURES

Crank & Axle
3-Piece Crank

Drive Belt
Quiet Belt Drive System, Hutchinson

Pedals
Oversized, Adjustable Pedals

Gear Ratio
N/A

Resistance System
400 Watt EMS Brake Resistance System

Heart Rate Monitoring
Dual EKG Pulse Sensors, ANT+ and Polar Compatible

Workout Fan
N/A

Accessory Charging
USB Charging Port

Accessory Holder(s)
Dual Water Bottle Holders, Phone Holder

Grips
Soft touch, upper-body grips

Seat
Overmolded Quick Adjust Seat

Accessibility
Highly-Accessible Step-Thru™ Design

Positioning
Large Adjustable Leveling Feet

Transport Wheels
2 in / 5 cm plastic transport wheels

Color Options
N/A (Flat Black is standard color)

Unit Options
Metric or Imperial

Power Options
110-120 VAC, 2 Amp
220-240 VAC, 1 Amp

PRODUCT SPECIFICATIONS

Maximum User Weight
400 lb / 181 kg

Resistance Levels
1-24 Levels of Resistance

DIMENSIONS & WEIGHT

Product Dimensions L x W x H
50 x 24 x 58 in / 127 x 60.9 x 147.3 cm

Product Weight
176.4 lb / 80 kg

Shipping Dimensions L x W x H
53 x 24 x 58 in / 134.6 x 60.9 x 147.3 cm

Shipping Weight
206 lb / 93.4 kg

POWER REQUIREMENTS

U.S. & Canada
110-120 VAC, 2 Amp

International
220-240 VAC, 1 Amp

HIGH-USAGE WARRANTY (US & CANADA)

Frame: 7 Years
Parts: 2 Years
Console: 2 Years
Labor: 1 Year
Cosmetic & Wear Items: 6 Months

HIGH-USAGE WARRANTY (INTERNATIONAL)

Frame: 7 Years
Parts: 2 Years
Console: 2 Years
Labor: 1 Year
Cosmetic & Wear Items: 6 Months

LOW-USAGE WARRANTY (US & CANADA)

Frame: 7 Years
Parts: 3 Years
Console: 3 Years
Labor: 3 Years
Cosmetic & Wear Items: 6 Months

LOW-USAGE WARRANTY (INTERNATIONAL)

Frame: 7 Years
Parts: 3 Years
Console: 3 Years
Labor: 1 Year
Cosmetic & Wear Items: 6 Months

Additional information

Weight	206 lbs
Dimensions	53 × 24 × 58 in
